Max Series UR23036 Angle Stop Ball Valve, 1/2 x 3/8 in Connection, Push-To-Connect x Compression

Description

SharkBite® max angle stops are used on stub-outs coming out of the wall and are used to control and shut off water flow to fixtures and appliances for maintenance and repair. Innovative design with a 1/2 in push-to-connect inlet makes for quick-installation and quarter-turn full port brass ball valves make for easy operation. Ideal for working in tight spaces. Faster install times and ease of use reduce installation errors.

• Fastest way to connect PEX, copper, CPVC, PE-RT or HDPE SDR-9 pipe
• Can be installed on wet lines and is pressure testable immediately
• Stainless steel retainer adds strength and durability
• High-performance DZR lead-free brass body
• No special tools, crimping, glue or soldering required
• Can be rotated after installation
• No tube liner required for PEX
• Can be easily removed using a disconnect clip, disconnect tongs or pro disconnect tool

Connection Size1/2 x 3/8Connection TypePush-To-Connect x CompressionPort TypeFull, Quarter-TurnPressure Rating125Temperature Rating160MediaWaterTrim MaterialStainless SteelSoftgoods MaterialEPDMBody MaterialDZR BrassFinishChrome-PlatedDimensions2.6 x 1.7 x 1.1Suitable forCopper, CPVC, PE-RT, PEX or HDPE SDR 9 Pipes
