TBV6F-8 Gas Ball Valve, 3/8 x 1/2 in Connection, Flared x FIP, 5 psi Pressure

Description

BrassCraft’s exclusive line of Italian made gas ball valves are specially engineered to provide unsurpassed product performance. From the stem to the body to the exclusive handle design, every detail has been master crafted for ease of operation and installation. This valve can be installed in the gas line run of copper tubing. Requires a 1/2 in OD flare nut to install.

• Forged brass body eliminates pinhole leaks commonly associated with cast products
• Blowout proof stem assembled from the inside with double O-ring to ensure safe, reliable performance
• PTFE seats assure a tight seal and easy on and off operation even after long periods of inactivity
• Comfort-fit grip handle features an exclusive integration of the T and lever handle designs
• 1/4 turn operation provides easy on and off flow control
• 100% leak tested
• Use with natural, manufactured, mixed and liquefied petroleum (liquid propane or propane) gases and liquid propane gas-air mixtures

Connection Size3/8 x 1/2Connection TypeFlared x FIPPressure Rating5Temperature Rating-40 to 150Body MaterialBrassMediaLPG Air MixturesSoftgoods MaterialPTFE/RubberDimensions2.3 in L x 1.45 in HIncludes9/16 -24 Fine Thread
